Scrap Metal Shredder

Scrap Metal Shredder from Henan Recycling

Machine Description

Double shaft shredders are mainly composed of shredder blades, spacing sleeves, spindles, knives, carrier boxes, lower racks, feed hoppers, motors, gearboxes and electronic controls,used to shred the feeding material into "Long" pieces.

Which type material can be shred by scrap metal shredder?

1. Variety containers: plastic beverage cans, plastic barrels, drums, crates, packaging barrels,PP bottle,PE pet bottle.
2. Waste appliances: TV, washing machine, refrigerator shell, printer, keyboard, waster Microwave oven,waster computer,waster mouse,Circuit board.
3. Pipe: large pipe, pipe fittings, PE pipe,PVC tube.
4. Wood: wooden pallets, plastic pallets, forklift pallets,Used furniture.
5. Rubber:waster wire, tires tires, truck tires.
6. Scrap metal: car shell, aluminum, scrap aluminum, engine shell, Lead plate,waster steel,waster iron.
7. Garbage:Food waste,animal carcass, medical waste, garden garbage,Fruit trash,Vegetable trash,glass

Shredding process:

1 Feeding conveyor

First through the scrap mill grasp to sending the scrap metal on the conveyor,and then through the

feeding conveyor to convey the scrap waste into scrap metal shredder.
The feeding conveyor speed generally can be controlled.
And most customer running site does't need the feeding conveyor.

2 Shredder machine

After material feeding into shredder,in the chamber box there is the balde in,through the motor driving

the gearbox and coupling to keep the blade running,then reach the purpose of the shredding.

The shredder machine blade with 5 different type ,according to customer requirments to matched

different blade.

3 Output Conveyor

The scrap metal from the shredder generally around width10mm-70mm by 30-300mm.

Through this conveyor to transport the output conveyor.

4 Metal Hammer Mill(Optional)
The hammer mill used to turn the output from shredder into "ball"shape to increase the density of

scrap metal.

Feature of the scrap metal shredder

1 thick knife, high productivetion , the tools are used alloy tools, durable and long life.

2 frame structure, high torque resistance, high compressive strength.

3 Microcomputer (PC) automatic control, set start, stop, reverse and overload automatic reverse control.

4 With low speed, high torque, low noise, dust can reach the characteristics of environmental standards.

5 easy to adjust, low maintenance costs, economic and durable.

6 The thickness of the tool and the number of knives can be changed according to different materials.

Part Type Machine Parameter
